Professional Sand Casting Mould Supplier Custom Sand Core Moulds, Cast Iron Patterns & Pattern Making Tooling

This Sand Casting Mould product family covers sand core moulds, cast iron patterns, pattern plates, and pattern making tooling for foundry production. Each tool is produced from the customer’s casting drawing and matched to the foundry’s molding method, whether green sand or resin sand. The mould is used to form cavities in the sand mold and to create cores for internal passages and recesses. Cast iron and aluminum tooling bodies are available depending on handling needs and production conditions. OEM customization covers pattern layout, core box configuration, and gating provisions, adapting the Sand Casting Mould to different molding lines and casting programs.This Sand Casting Mould product family covers sand core moulds, cast iron patterns, pattern plates, and pattern making tooling for foundry production. Each tool is produced from the customer’s casting drawing and matched to the foundry’s molding method, whether green sand or resin sand. The mould is used to form cavities in the sand mold and to create cores for internal passages and recesses. Cast iron and aluminum tooling bodies are available depending on handling needs and production conditions. OEM customization covers pattern layout, core box configuration, and gating provisions, adapting the Sand Casting Mould to different molding lines and casting programs.

Material of Sand Casting Mould:

USA Brand : A360,A380,A356,A383 ECT

Application:

• Cast Iron Pump and Valve Bodies
  Tooling for fluid-handling castings produced in iron foundries.

• Automotive and Transport Castings
  Patterns and core boxes for brackets, housings, and supports used in vehicle and transport manufacturing.

• Machine Tool Beds and Columns
  Sand Casting Mould tooling for large cast iron structures used in machine tool production.

• Agricultural and Construction Machinery Parts
  Tooling for wear parts, supports, and housings used in off-highway equipment.

• General Industrial and OEM Foundry Production
  Patterns and core boxes for a range of commercial castings supplied to OEM production lines.

Production Process:

1. Review the part design,drawings and quality standard from clients.
2. Mould and Tooling design & manufacturing
3. Mould and Tooling testing & confirm the sample
4. Die casting raw castings
5. Surface treatment: Trimming,Deburring, polishing, cleaning, passivation & power coating and other requirement from Customer
6. Precision machining: CNC lathes, milling, drilling, grinding etc
7. Full Inspection
8. Packing
9. Delivery

Quality Control

1) Checking the raw material after they reach our factory------- Incoming quality control ( IQC)

2) Checking the details before the production line operated

3) Have full inspection and routing inspection during mass production---In process quality control(IPQC)

4) Checking the goods after they are finished---- Final quality control(FQC)

Packaging & Shipping

Our products are all packed in wooden cases to ensure zero damage. If customers have specific requirements for the packaging, we will gladly accommodate. The products will be sent to you on time and we will arrange everything from the initial consultation to the delivery of your chosen port anywhere the world. We can also customize the packing method according to customers' needs. Suitable for seaway transportation.
