Professional Custom Sand Casting Mould for Aluminum Alloy Parts OEM Pattern, Pattern Plate & Core Box Tooling Manufacturer

This sand casting mould is supplied as a complete foundry tooling package for aluminum alloy part production. The set includes patterns, pattern plates, and core boxes, all machined from the customer’s casting drawing. Patterns define the mold cavity, while core boxes produce the sand cores that form internal passages and recesses. The tooling is compatible with green sand and resin sand molding methods and is built for repeated use in foundry production. OEM customization covers pattern layout, gating arrangement, and core box configuration to suit different molding lines and part geometries.

Material of Sand Casting Mould:

USA Brand : A360,A380,A356,A383 ECT

Application:

1. Aluminum Automotive Castings
   Tooling for intake manifolds, housings, brackets, and other aluminum components produced by sand casting.

2. Pump and Valve Bodies
   Patterns and core boxes for aluminum pump bodies, valve bodies, and impellers used in fluid handling systems.

3. Electrical and Electronic Housings
   Mould tooling for aluminum enclosures, junction boxes, and heat sink bodies cast through sand molding.

4. Industrial Machinery Components
   Tooling for brackets, covers, and structural parts produced in aluminum foundries.

5. General Engineering and OEM Castings
   Patterns and core boxes for a range of aluminum castings used in commercial and industrial equipment.

Production Process:

1. Review the part design,drawings and quality standard from clients.
2. Mould and Tooling design & manufacturing
3. Mould and Tooling testing & confirm the sample
4. Die casting raw castings
5. Surface treatment: Trimming,Deburring, polishing, cleaning, passivation & power coating and other requirement from Customer
6. Precision machining: CNC lathes, milling, drilling, grinding etc
7. Full Inspection
8. Packing
9. Delivery

Quality Control

1) Checking the raw material after they reach our factory------- Incoming quality control ( IQC)

2) Checking the details before the production line operated

3) Have full inspection and routing inspection during mass production---In process quality control(IPQC)

4) Checking the goods after they are finished---- Final quality control(FQC)

Packaging & Shipping

Our products are all packed in wooden cases to ensure zero damage. If customers have specific requirements for the packaging, we will gladly accommodate. The products will be sent to you on time and we will arrange everything from the initial consultation to the delivery of your chosen port anywhere the world. We can also customize the packing method according to customers' needs. Suitable for seaway transportation.

Company profile:

Luoyang Liushi mould Co., Ltd was established on 2001, which is National Standard Setting Unit for Lost Foam Casting Mould. The company is located in the Millennium Emperor, peony flower city of Luoyang City. We have 9800 office building, and 22000 workshop, which is well equipped with research, development, design, foundry, machining, assembly, surface treatment and other equipment. It′s a Luoyang municipal R&D center and technology center.

Why Choose Us

1. Molding Process Review Before Tool Design
   We examine the intended molding method and casting geometry before finalizing pattern layout, parting line, and core box details.

2. In-House Pattern Making, Machining, and Assembly
   Tooling production is handled internally, allowing direct communication and faster response to design changes.

3. Traceable Tooling Material Sourcing
   Tooling materials are sourced with documented traceability to support consistent mould construction and quality verification.

4. Foundry Trial Support
   Sample patterns and core boxes can be tested before shipment, helping confirm fit, release, and dimensional performance.

5. OEM/ODM Project Handling
   Tooling is built to customer drawings and can be adapted for different molding machines, core shooters, and production volumes.

FAQ:

1.How can I get the quotation?

Please give us your drawing, quantity, weight and material of the product.

2.If you don't have the drawing,can you make drawing for me?

Yes, we are able to make the drawing of your sample duplicate the sample.

3.When can I get the sample and your main order time?

Sample time: 15-30 days after start to make mold.

Order time: 35-40 days, the accurate time depends on product.

4.What is your payment method?

Tooling: 50% T/T in advance, after sample approved pay balanced.

Order time: 30% deposit, 70% against copy of B/L.

5.Which kind of file format you can read?

PDF, IGS, DWG, STEP, JPG, PNG, MAX

6.What is your surface treatment?

Including: powder coating, sand blasting, painting, polishing, acid pickling, anodizing, enamel, zinc plating, hot-dip galvanizing, electrophoresis, chrome plating.

7.What is your way of packing?

Normally we pack goods according to customers' requirements.
